| Machine suitable for drum bead |
15" ~ 16" (dual bead) |
| Drum outer diameter |
15"- 492∮ 16" - 516∮ drum width
adjustment by spacer 8 pieces auto collapse |
| Machine suitable for drum shoulder width |
390 ~ 730M/M |
| Drum rotating speed |
High speed 200/ low speed 100 RPM |
| Center height of main shaft from floor |
1160MM |
| U/R under stitcher |
1.3 stage changeable speed |
| 2.Drum per cycle under roller stitcher (U/R) traverse
7mm ~ 15mm. |
| 3.Thickness of tread and sidewall will influence U/R
traverse's speed. |
| Tread server |
1.Position: in front of the operator or in rear of the
operator as specify |
| 2.Drum one-revolution, tread will ply with building
drum automatically. |
| 3.Features: device of centering and proper lead the
tread to the drum center. |
| 4.Dimension of servicer: 1600(L) 500(W) |
| Band applicator |
1.Expand outer diameter: 2mm tolerance with building
drum. |
| 2.Put the band on the band applicator drum and rotary
90 degree then expand automatically. |
| 3.Band ply with drum use spinner shaft which will send
the band to the drum center automatically. After plying, the band applicator will
backwards to its original position. |
| 4.Outer diameter of band spinner shaft: 50∮×2100MM(L) |
| 5.Brake system: hydraulic disc brake |
| Dimension & Weight of Machine |
600CM(L)220CM(W)220CM(H) 11000KG |
